Can-Am Defender Rear Control Arm Link Bar Kit High Lifter

Can-Am Defender Rear Control Arm Link Bar Kit

Protect your lifted Defender with the High Lifter Can-Am Defender rear control arm link bar kit. Built for demanding off-road use, this heavy-duty rear suspension upgrade helps protect control arms and frame tabs from impact stress caused by rocks, logs, deep mud, rough trails, jumps, and winching strain.

A control arm or A-arm is strongest against side-to-side force, but it can be more vulnerable to front and rear impact. When your Can-Am Defender takes a hard hit or gets pulled through thick mud, the rear control arms and mounting points can bend or fail. This Can-Am Defender Rear Control Arm Link Bar Kit adds extra reinforcement to help reduce costly suspension damage and keep your UTV ready for the next ride.

Key Features

• Heavy-duty rear control arm link bars help protect control arms and frame tabs from impact stress.
• Up to 10 inches of length adjustability for flexible fitment on compatible lifted Defender models.
• Clamp collars available for 1-1/4 inch or 1-1/2 inch DOM-style control arm tubing.
• 1/4 inch mounting plates provide added strength for mud, trail, and rock riding.
• 3-piece Heim joints are crafted from heat-treated chromoly for superior durability.
• Powder-coated finish helps resist corrosion, mud, debris, and off-road wear.
• Easy bolt-on design requires only minor drilling.
• Includes mounting hardware and skid plate trimming templates for most models.

Technical Specifications

• Brand: High Lifter
• Product Type: Rear Control Arm Link Bar Kit
• Application: Can-Am Defender rear suspension protection
• Position: Rear
• Adjustability: Up to 10 inches
• Clamp Collar Options: 1-1/4 inch or 1-1/2 inch
• Clamp Compatibility: DOM-style control arm tubing
• Joint Type: 3-piece Heim joints
• Joint Material: Heat-treated chromoly
• Mounting Plates: 1/4 inch plates
• Finish: Powder coated
• Installation: Bolt-on with minor drilling required
• Hardware: Included

Compatibility / Applications

This Can-Am Defender rear control arm link bar kit fits select 2020–2025 Can-Am Defender HD10 models, including Defender HD10, Defender MAX HD10, Defender PRO HD10, and Defender HD10 6×6 trims.

• Fits select 2020–2025 Can-Am Defender HD10 models
• Fits select Can-Am Defender HD10 DPS, XT, Limited, X MR, and XTP models
• Fits select Can-Am Defender MAX HD10 DPS, Limited, Lone Star, XT, and X MR models
• Fits select Can-Am Defender PRO HD10 DPS, Limited, and XT models
• Fits select Can-Am Defender HD10 6×6 DPS, Limited, and XT models

Installation Requirements

• Requires a big lift kit with 1-1/4 inch or 1-1/2 inch DOM tubing.
• Works with Big Lift Kits only that use 1-1/4 inch or 1-1/2 inch DOM tubing.
• 1-1/2 inch clamps are compatible with High Lifter Apex control arms.
• Not compatible with SuperATV Atlas control arms.

Why Choose This Product?

The High Lifter Can-Am Defender rear control arm link bar kit is built for riders who demand stronger suspension protection from their lifted UTV. Whether you ride deep mud, rocky trails, wooded terrain, or heavy-duty work environments, this kit helps reinforce the rear suspension where impact stress can cause expensive damage.

With adjustable link bars, chromoly Heim joints, reinforced mounting plates, and a durable powder-coated finish, this kit is a reliable upgrade for Can-Am Defender HD10 owners who want long-lasting durability, better control arm protection, and professional-grade off-road strength.

Fitment Note: Please confirm clamp size, big lift kit requirements, and control arm compatibility before ordering. This kit will not work with SuperATV Atlas control arms.

Cross-reference part/SKU numbers: 79-12168, 79-12167, CAL-R-C1D-HD, CAL-R-C1D
